Maruti Ertiga vs XL6: Interior Space Comparison

Published On Dec 27, 2019 06:47 PM By Dhruv Attri for Maruti Ertiga 2015-2022

112.7K Views
Write a comment

Does the added premiumness take away any bit of practicality from the XL6 when compared to the Ertiga?

The Maruti Ertiga is well established as a people mover thanks to its practicality, three rows of seating and excellent ergonomics. But the Maruti XL6 promises to top that up with premiumness and offer extra comfort to passengers in the second row by offering captain seats. So how different are the two exactly when the measuring tape comes out?

Dimensions

Measurement (in mm)	Maruti Ertiga	Maruti XL6
Length	4395	4445
Width	1735	1775
Height	1690	1700
Wheelbase	2740	2740
Boot space (litres)	209, 550-(3rd row folded), 803 (2nd and 3rd row folded)	209, 550-(3rd row folded), 692 (2nd and 3rd row folded)

The XL6 has bigger proportions than the Ertiga from the outside but both have the same wheelbase.
Even the boot space is similar if you have all three rows up or the third row down. But differences are quite evident when you have to fold the second row.
The Ertiga offers the most boot space when you need it thanks to its second-row bench seat in comparison to the captain seats in the XL6.

Front Row Space

Measurement (in mm)	Maruti Ertiga	Maruti XL6
Legroom (min-max)	860-1000	860-100
Kneeroom(min-max)	550-770	550-770
Headroom(min-max)	975-1040	975-1040
Seat base length	485	485
Seat base width	495	495
Seatback height	600	600
Cabin width	1360	1360

As the numbers reveal, both the Ertiga and XL6 are absolutely identical when it comes to the front row.

Second-Row Space

Measurement (in mm)	Maruti Ertiga	Maruti XL6
Shoulder room	1375	1375
Headroom	990	1000
Knee room (min-max)	520-850	550-880
Seat base width	1280	550 (X2)
Seat base length	500	500
Seat back height	570	570

The XL6 has a smidge more headroom than the Ertiga.
However, the biggest difference is in terms of seat base width since the XL6 gets captain seats and the Ertiga gets bench seats.
If you spend most of your time in the second row, then the XL6 should serve you better but if you require seating for three, then it is the Ertiga that makes more sense.

Third-Row Space

Measurement (in mm)	Maruti Ertiga	Maruti XL6
Shoulder room	1325	1325
Headroom	890	890
Seat base width	1000	1000
Seat base length	445	445
Seat base Height	540	540
Kneeroom (min-max)	580-700	620-830
Seat base height from floor	320	320

Third-row passengers in the XL6 are bound to get slightly better knee room given that the second row has offers some space between the two captain seats. So spending a longer time in that last row will be a tad easier in the XL6 than the Ertiga.
All the other dimensions are exactly the same.
